Medical equipment panel
Parameter (Specification)
|
Item |
Specification |
|||
|
Item No. |
G080-1191255801-L45PNZ |
|||
|
Panel Size |
8" inch |
|||
|
Display Area (mm) |
176.64(H) ×99.36(V) |
|||
|
Number of Pixels |
1280(H) x 720(V) |
|||
|
Pixel Pitch (mm) |
0.138(W)x 0.138(H) |
|||
|
Color Pixel Arrangement |
RGB Vertical stripe |
|||
|
Display Mode |
Normally Black |
|||
|
Number of Colors |
16.7M(8bits) |
|||
|
Brightness(cd/m2) |
800 nits(typ) |
|||
|
Response Time (ms) |
30ms(typ) |
|||
|
Color Gamut |
70%(typ) |
|||
|
Viewing Direction |
Free |
|||
|
Contrast ratio |
900:1 |
|||
|
Interface connection |
LVDS interface |
|||
|
Module Size(mm) |
|
Min. |
Typ. |
Max |
|
Horizontal (H) |
187.92 |
188.22 |
188.52 |
|
|
Vertical (V) |
113.66 |
113.96 |
114.26 |
|
|
Depth (D) |
5.9 |
6.2 |
6.5 |
|
|
Module Weight (g) |
TBD |
|||
|
Backlight Unit |
LED |
|||
|
Surface Treatment |
HC 3H |
|||
Product details
The Customized Features of TFT-LCD Panel we can support
- Brightness
- Color Temperature
- FPC length / shape / definition / position … etc
- Mechanical
- Working / Storage temperature
- POL
- Interface
- Direction scan
Factory equipment / machines:
- Panasonic COG fully automatic machines
- FOG automatic bonding machine
- 3 in 1 automatic dispensing machine
- Automatic cleaning machine
- Automatic material-loading machine
- High temperature and high humidity tester
Our partnership:
- Honda
- Suzuki
- Proton
- GM
- YEMA
- GEELY
- Hisense
- LEPU Medical
- Create & Care Medical
- World Hotel
FAQ
Q: How do I get started working with your company?
Q: What are the steps involved in a repair or maintenance service?
Diagnostic testing
Parts procurement
Repair or replacement
Quality control
Q: What types of Typical LCD Viewing Angles?
IPS (In-Plane Switching) Panels: Wider viewing angles, typically around 178°.
VA (Vertical Alignment) Panels: Wide viewing angles, usually around 178°.
Measuring LCD Viewing Angle:
LCD viewing angles are measured using the "10:1 Contrast Ratio" method. This involves measuring the contrast ratio of the panel at various angles from the center. The viewing angle is defined as the angle at which the contrast ratio drops to 10% of its maximum value.
Introduction
TFT LCD panel panel 8 Inch 1920x1200 IPS 800 nits 16:10 Aspect ratio LVDS 40 pins interface 900:1 Contrast LCD module Automotive grade.
The application advantages of 8.0-inch medical TFT LCD panel mainly include high resolution and wide viewing angle, low power consumption and high reliability, lightweight and portable, and excellent visual experience.
High resolution and wide viewing angle: The 8.0-inch medical TFT LCD panel has the characteristics of high resolution and wide viewing angle, which can ensure that doctors can see clear and realistic images and text from any angle, and the details and colors of the picture are also excellent. This characteristic is crucial for information panel in medical diagnosis and treatment processes, helping to improve the accuracy and efficiency of diagnosis.
Low power consumption and high reliability: This panel also has the characteristics of low power consumption and high reliability. The low-power design allows the device to maintain low battery consumption after long-term use, which is particularly important for mobile devices. At the same time, high reliability ensures that the LCD screen can work stably in various environments, and even under extreme conditions, there will be no problems such as image distortion or color deviation, thus ensuring the stable operation of medical equipment.
Lightweight and portable: The 8.0-inch medical TFT LCD panel also has the characteristics of being lightweight and portable, making it an ideal choice for mobile devices such as handheld medical devices. At the same time, due to its small size and light weight, it also makes the device more convenient to carry, bringing more convenience to medical staff.
Excellent visual experience: Due to the use of advanced TFT technology, the 8.0-inch medical TFT LCD panel has fast response time and smooth dynamic image panel, providing users with a better visual experience. This is very important for various application scenarios in the medical field, such as operating rooms, diagnostic rooms, etc., as it helps to improve the work efficiency of medical staff and patient satisfaction.
The 8.0-inch medical TFT LCD panel has a wide range of application advantages in the medical field due to its high resolution and wide viewing angle, low power consumption and high reliability, lightweight and portability, and excellent visual experience.
